SPX OTC 1794A - Replacement Parts Kits

Sheet No.
Issue Date: Rev. E Jan. 25, 2006
© 2004 SPX Corporation
Parts List & Operating Instructions Form No. 528220
Replacement Parts Kits
Air Kit No. 529037
31 1 Bolt
32 1 O-ring
33 1 O-ring
34 1 Coupler
35 1 Snap Ring
36 1 Muffler
37 2 Adjustor
38 2 Joint
40 2 Pipe
42 2 Joint
43 3 Lock Washer
44 3 Bolt
45 3 Flat Washer
46 1 Fixing Board
Caster Kit No. 529035
48 4 Nut
49 4 Lock Washer
50 2 Swivel Caster A
52 2 Swivel Caster B
Foot Pedal Kit No. 529036
39 1 Rod
53 1 Spring
58 2 Rod
59 2 Seal
60 2 Joint
61 2 Spring
62 2 Copper Washer
63 2 Air Release Valve
64 2 O-ring
65 2 Washer
66 2 Snap Ring
67 2 Air Release Rod
68 1 Up Pedal
69 1 Down Pedal
70 5 Pin
71 5 Pin
72 1 Rod
73 1 Nut
Handle Kit No. 529038
17 1 Copper Washer
77 1 Handle Sleeve
78 1 Handle
79 1 Snap Ring
81 1 Handle Socket
82 1 Pin
83 1 Pin
84 1 Pump Plunger
85 2 Nylon Gasket
86 2 O-ring
87 1 Pump Cylinder
88 1 Pump Seat
Hardware Kit No. 529042
91Pin
10 1 Release Knob
31 1 Bolt
43 3 Lock Washer
44 3 Bolt
45 3 Flat Washer
48 6 Nut
49 12 Lock Washer
51 8 Bolt
53 1 Spring
70 5 Pin
71 5 Pin
79 1 Snap Ring
82 1 Pin
83 1 Pin
92 2 Hook
93 4 Washer
94 4 Nut
95 2 Bolt
97 2 Screw Cap
99 4 Bolt
101 2 Screw
102 2 Link
103 2 Safety Chain
105 2 Washer
109 2 Locknut
113 1 Bolt
114 8 Snap Ring
118 2 Knob
120 2 Pin
Hydraulic Kit No. 529041
11Bolt
22O-ring
31Screw
41Spring
51Ball Seat
61Steel Ball
71Steel Ball
81Oil Release Valve Rod
91Pin
10 1 Release Knob
11 1 Copper Washer
12 1 Bolt
13 2 Steel Ball
14 2 Spring
15 2 Steel Ball
16 2 Screw
17 2 Copper Washer
18 2 O-ring
19 2 Nylon Washer
20 2 O-ring
21 1 Guide Ring
24 1 Screw
25 2 O-ring
26 1 Nylon Washer
27 1 Guide Ring
30 2 Snap Ring
55 1 Y-seal
56 1 Bushing
57 1 Bushing
89 2 Bolt
90 2 Lock Washer
121 1 O-ring
Tilt Screws No. 529039
106 1 Shaft
107 1 Screw
109 2 Locknut
110 2 Shaft
111 4 Bearing
112 2 Bushing
114 8 Snap Ring
115 2 Shaft
117 1 Screw
118 2 Knob
119 1 Shaft
120 2 Pin
Saddle Kit No. 529040
92 2 Hook
93 4 Washer
94 4 Nut
95 2 Bolt
96 2 Fixing Bracket A
97 2 Screw Cap
98 2 Corner Bracket
99 4 Bolt
100 2 Fixing Bracket B
101 2 Screw
102 2 Link
103 2 Safety Chain
104 1 Universal Saddle
105 2 Washer
108 1 Bracket
113 1 Bolt
116 1 Bracket
Item
No. Qty. Description
Item
No. Qty. Description
Item
No. Qty. Description
2 of 4
