I-Line™ Combo Switchboards 80043-808-02 Rev. 02
Installation—ECB, EDB, EGB, and EJB Circuit Breaker Installation and Removal 03/2017
16
ENGLISH
8. Reinstall the lighting section interior trim cover and large interior trim
cover (Figure 2, on page 12).
9. Ensure the I-Line section connection is free of debris
before re-energizing.
10. Re-energize the I-Line Combo switchboard.
11. Turn the circuit breaker ON.
ECB, EDB, EGB, and EJB Circuit Breaker Removal
Refer to Figure 5, ECB, EDB, EGB, and EJB Circuit Breaker Installation
and Removal, on page 17, for the following instructions.
1. Turn OFF all power to the I-Line Combo switchboard.
2. Turn the circuit breaker OFF.
3. Remove the large interior trim cover and the lighting section interior
trim cover (Figure 2, Interior Trim Removal, on page 12).
4. Remove the load wire. Secure the wire and cover the exposed end.
5. Loosen the screw(s) in the circuit breaker connector and lift the circuit
breaker OFF of the branch connector.
6. Insert circuit breaker blank fillers in the lighting section interior trim
cover (Figure 8, Lighting Section Interior Trim Preparation,
on page 21).
7. Reinstall the lighting section interior trim cover and large interior
trim cover.
8. Ensure the I-Line section connection is free of debris
before re-energizing.
9. Re-energize the I-Line Combo switchboard.
WARNING
POTENTIAL OF EQUIPMENT OVERHEATING
Do not overload this section by exceeding the maximum calculated
load in accordance with NEC Article 220, as shown on the section
nameplate label.
Failure to follow these instructions can result in death, serious
injury, or equipment damage.
80043-808-01.book Page 16 Wednesday, March 22, 2017 12:31 PM

Square D I-Line Specifications

General

Bus Material	Aluminum or Copper
Voltage Rating	600V AC
Current Rating	Up to 1200A
Enclosure	NEMA 1
Poles	2, 3
Interrupting Rating	200 kA (depending on the specific model and installed breakers)
