I-Line™ Combo Switchboards 80043-808-02 Rev. 02
Appendix 2: Accessory Kits 03/2017
56
ENGLISH
Appendix 2: Accessory Kits
An assortment of field-installable accessory kits are available for
I-Line Combo switchboards:
• Equipment Ground Bar Kits, on page 56
• Compression Lug Kits for MG, MJ, L, and P
Circuit Breakers, on page 57
• Circuit Breaker Lug Kits, on page 58
Equipment Ground Bar Kits
Equipment ground bar kits, suitable for copper or aluminum wire, meet the
grounding needs of I-Line Combo switchboards. Select the required kit
according to the interior catalog number. Kits can be field installed.
Table 10: Equipment Ground Bar Kits Specifications
Switchboard
Use Ground Bar Kit Catalog Number
Aluminum
1
Copper
2
All PK32DGTA PK32DGTACU
1
Aluminum bars are suitable for 140° F or 167° F (60° C or 75° C) copper or aluminum conductors.
2
Copper bars are suitable for 140° F or 167° F (60° C or 75° C) copper conductors.
NOTE: Ground bar mounting locations are identified by the ground symbol stamped into the back wall of
the enclosure.
80043-808-01.book Page 56 Wednesday, March 22, 2017 12:31 PM

Square D I-Line Specifications

General

Bus Material	Aluminum or Copper
Voltage Rating	600V AC
Current Rating	Up to 1200A
Enclosure	NEMA 1
Poles	2, 3
Interrupting Rating	200 kA (depending on the specific model and installed breakers)
