SRAM rock shox Setup Guide

16
Note the sag percentage where the o-ring
stopped.
If your target sag percentage is not
achieved, spring preload adjustment must
be performed.
Coil spring preload in RockShox® Paragon™
is an internal adjustment that compresses or
decompresses the spring without initiating
travel.
The coil spring can be preloaded 5 mm or
10 mm with the internal preload spacer.
Remove the top cap to remove or re-orient
the internal preload spacer.
A) Standard 5 mm (factory installed) preload
spacer orientation.
B) To decrease preload and increase sag,
remove the preload spacer.
C) To increase preload and decrease sag,
reorient the preload spacer to the 10 mm
preload position.
Repeat the sag process until your target sag
percentage is achieved.
A
B
C
20%
>30%
<10%
AdjustMeasure
