To achieve maximum suspension performance, proper setup and tuning is essential.
This guide will help you identify and understand the features and adjustments that may be included on
your RockShox® suspension fork, as well as guide you through spring setup, damper adjustments and
tuning, and air spring bottom out tuning.
Tuning suggestions are starting points. It may take trying various adjustments to find the settings that
work best for each individual rider and trail condition.
Try the Quarq® ShockWiz™ suspension tuning device for more detailed ride data analysis and setting
suggestions. Go to www.quarq/shockwiz.com for more information.
For quick setup after fork service and tuning has been performed, make a note of your fork
settings on page 31.
Go to www.rockshox.com/app for suggested air spring pressure and rebound damper
settings for your fork.
Go to www.sram.com/service for additional product and technical information.
• Air spring pressure and coil spring tables are available in the RockShox® Front
Suspension Oil, Air, Coil, Token, and Specification documents.
• For a complete list of available coil springs and Bottomless Tokens™,
consult the RockShox Spare Parts Catalog.
• Consult the RockShox service manual for your fork for complete
disassembly and assembly procedures.
Your product's appearance may differ from the images in this
publication.
All setup procedures picture the fork only. Perform actual fork
sag and tuning on a complete, assembled bicycle.
All performance examples illustrated are for conceptualization
and may vary from actual performance.
Compression
Damper
Adjusters
Spring
(Air or Coil)
Rebound
Damper
Adjuster
