12
Bottomless Tokens Installation (optional)
Solo Air: Use a flat blade screwdriver to push the SA seal head tab
under the retaining ring.
NOTICE
Scratches on the air shaft will allow air to bypass the seal head into
the lower leg, resulting in reduced spring performance.
Place the tips of large internal retaining ring pliers into the eyelets of
the retaining ring.
2018 DebonAir and Solo Air: Press firmly on the pliers to push the SA
seal head into the upper tube enough to compress and remove the
retaining ring. Slide the retaining ring onto your finger and release the
air spring shaft.
2019-2022 DebonAir: Push the air shaft into the upper tube with your
thumb. While holding the shaft in, remove the retaining ring. Slide the
retaining ring onto your thumb and carefully release the air spring
shaft.
2
2
2018 DebonAir and Solo Air
2018 DebonAir and Solo Air
