Lyrik / Pike / Revelation / Yari / ZEB DebonAir Upgrade Kit Installation
Lyrik / Pike / Revelation / Yari / ZEB DebonAir Upgrade Kit Installation
Lower Leg Removal
Remove the air valve cap from the top cap located on the non-drive
side fork leg.
Use a small hex wrench to depress the Schrader valve and release all
air pressure from the air chamber.
⚠ CAUTION  EYE HAZARD
Verify all pressure is removed from the fork before proceeding.
Failure to do so can result in injury and/or damage to the fork. Wear
safety glasses.
Use a 2.5 mm hex wrench to loosen the set screw and remove the
rebound adjuster knob located at the bottom of the drive side fork leg.
Use a 5 mm hex wrench to loosen both bottom bolts 3 to 4 turns.
1
2
3
2.5 mm
Spring Side
Damper Side
4
