SRIXON QTS - How to Remove and Install QTS Sleeve (Sleeve Installation)

Insert the shaft into the head
5
QTS setting examples
6
How to remove and install QTS sleeve
(
sleeve installation
)
Align the position line with
the mark and press straight in.
* Illustration shows neutral position
For
-
1LOFT(LOFT
-
1°)
Align the mark on the head with
“
-
1LOFT” on the QTS sleeve and press
straight in.
For
+
1LOFT(LOFT
+
1°)
Align the mark on the head with
“
+
1LOFT” on the QTS sleeve and press
straight in.
The shaft may not insert fully if the position line
and sleeve mark are not correctly aligned.
Press the shaft all the way in until the
QTS sleeve is completely covered.
05 06
