Battery wire
diameter
(mm2)
2.3 Installation and Wiring
Warning: risk of explosion! Never install the controller and an open
battery in the same enclosed space! Nor shall the controller be installed in an
enclosed space where battery gas may accumulate.
Warning: danger of high voltage! Photovoltaic arrays may produce a
very high open-circuit voltage. Open the breaker or fuse before wiring, and be
very careful during the wiring process.
Note: when installing the controller, make sure that enough air flows
through the controller's radiator, and leave at least 150 mm of space both above
and below the controller so as to ensure natural convection for heat dissipation.
If the controller is installed in an enclosed box, make sure the box delivers
reliable heat dissipation effect.
