01-23
3680-01
6. POWER FLOW
Power flows in gears:
Power flow - 1st gear (M)
Power flow - 1st gear (D)
Power flow - 2nd gear (D)
Power flow - 2nd gear (D) ? lockup (D)
Power flow - 3rd gear (D)
Power flow - 4th gear (D) - 4th gear (D) in Limp home mode
Power flow - 5th gear (D)
Power flow - 6th gear (D)
-
-
-
-
-
-
-
-
Gear
Gear ratio
Engaged element (clutch & band)
C1 C2 C3 B1 B2 1-2OWC
M1 3.53 ON ON
1st 3.53 ON ON
2nd 2.14 ON ON
3rd 1.48 ON ON
4th 1.16 ON ON
5th 0.87 ON ON
6th 0.68 ON ON
Reverse -3.09 ON ON
Gear
S1 S2 S3 S4 S5(A) S6(A) S7(A) S8(A) S9(A) S10(A)
M1 ON 1 0 1
1st ON 1 0 0-1
2nd ON ON 1 0 1 0-1
3rd ON ON 1 0 1 0-1
4th 0 0 0-1
5th ON 0 1 1 0-1
6th ON ON 0 1 1 0-1
Reverse ON ON ON 1 1 1 0-1
Gear Selection and Engaged Element
▶
Variable bleed solenoid valve - VBSON/OFF solenoid valve
