korando 2010.10
8810-00
AIR BAG SYSTEM
2. OPERATING CONDITIONS
1) Deploying Conditions for Front Air Bag
2) Deploying Conditions for Side Air Bag
Impact area Left side Right side
Seat belt pretensioner-driver side Deploy Deploy
Seat belt pretensioner-passenger side Deploy Deploy
Side air bag module-driver side Deploy Not deploy
Side air bag module-passenger side Not deploy Deploy
Inflatable curtain air bag module-driver side Deploy Not deploy
Inflatable curtain air bag module-passenger side Not deploy Deploy
Impact area Front side
Driver's air bag Deploy
Passenger's air bag Deploy
Seat belt pretensioner-driver side Deploy
Seat belt pretensioner-passenger side Deploy
When the ignition switch is turned to ON, SDM starts to diagnoses the air bag system during
the ignition process. If the system is OK, SDM is armed for a specific impact on the vehicle.
