0-3
RAIN SENSOR
KYRON 2007.04
0000-00
0000-00
RAIN SENSOR
1. TROUBLE SHOOTING
The wiper does not operate one cycle when turning the multifunction
wiper switch to the "AUTO" from the "OFF" position or starting the engine
while the wiper switch is in the "AUTO" position.
Symptom 1.
When starting the engine with the multifunction wiper switch in the "AUTO" position, the
wiper operates one cycle to remind a driver that the wiper switch is in the "AUTO" position.
When the wiper switch is turned to "AUTO" from "OFF", the wiper operates one cycle. It
always operates one cycle for the initial operation, however, the wiper does not operate
afterwards to prevent the wiper blade wear if not raining when turning the wiper switch to
"AUTO" from "OFF". However, the wiper operates up to 5 minutes after rain stops. If this
function does not occur, check No. 8 pin. If the pin is normal, check the wiper relay related
terminals in the ICM box.
1.
2.
It rains but the system does not work in the "AUTO" position.
Symptom 2.
Check whether the variable resistance knob on the multifunction wiper switch is set in "FAST".
The "FAST" is the highest stage of the sensitivity and very sensitive to small amount of rain
drops. Therefore, change the knob to the low sensitivity.
The wiper operates 3 or 4 times at high speed abruptly.
Symptom 3.
Check the wiper blade for wear. If the wiper blade cannot wipe the glass uniformly and
clearly, this problem could be occurred. In this case, replace the wiper blade with a new
one.
Check whether the variable resistance knob on the multifunction wiper switch is set in
"FAST". The "FAST" is the highest stage of the ensitivity and very sensitive to small amount
of rain drops. Therefore, change the knob to the low sensitivity.
1.
2.
The wiper operates continuously even on the dry glass.
Symptom 4.
Check whether the multifunction wiper switch is in the "AUTO" position.
Check the power to the sensor. Check the conditions of the pin 3 (Ground) and the pin 4
(IGN).
Check the wiper relay for defective.
1.
2.
3.
