Specifications
Signal detection method Oscillating chopper method
Display refresh frequency
0.5 seconds
Measurable potential range Normal mode: 0.00 - ±19.99kV (resolution: 0.01kV)
I.B mode: 0.000 - ±1.999kV (resolution: 0.001kV)
Continuous operating limit Approximately 10 hours (with alkaline battery)
Measuring distance 30 mm (between object being measured and sensor)
Measuring distance adjustment Red LED beam focusing method
Sensor head rotation angle 180° (stops every 45°)
Display LCD display with built-in backlight
Polarity display
＋ polarity/－ polarity display
Mode switching
Switch modes by pressing MODE button
Battery check
Remaining charge displayed in display panel
Battery DC9V alkaline rectangular dry cell battery 006P
Operating temperature/ humidity
range
0 - +40℃, 20 - 70％RH, non-condensing
Dimensions
68 mm x 22 mm x 138 mm (W x D x H)
Weight
Approximately 230g (including battery)
