5-52
5.4.14 CHAMBER ASSEMBLY
ITEM NUMBER
PART NUMBER DESCRIPTION QTY
1 35101 CHAMBER, 1200 SERIES 1
2 35083 W/A SHIELD, RADIATION 1
3 35329-02 ELEMENT, 2.5KW @120VAC 1
3 35329-01 ELEMENT, 2.5KW @ 220VAC 1
4 35152 INSULATOR 2
5 35131 ELECTRODE, 3KW HEATER 2
6 35104 SUPPORT, HEATING ELEMENT 2
7 35116 W/A STRIKE, LID LATCH, RH 1
8 35235 W/A ADJUSTMENT PLATE, RH 1
9 34717 DOWEL PIN, 1/4 DIA X 1.00 LONG 2
10 30021 SCREW, FH, SLOT, #6-32 X .38 LG, SS 4
11 31573 NUT, 1/4-20, STAINLESS STEEL 2
12 35129 WASHER, ANTI-ROTATION 2
13 35133 SPRING STOP, ELECTRODE 2
14 31378-35 SCREW, SHC, 1/4-20 X .75 LONG 2
15 35202 BRACKET, LID HINGE 1
16 31378-13 SCREW, SHC, 5/16-18 X 1.00 LONG 2
17 35115 PLATE, HINGE 1
18 35080 SHIELD, BOTTOM 1
19 31378-04 SCREW, SHC, 1/4-28 X 1 1/4, STL 4
20 35234 W/A ADJUSTMENT PLATE, LH 1
21 35122 SLEEVE, INSULATOR 2
22 31378-34 SCREW, SHC, #4-40 X .50 LONG, STL 4
23 35256 SWITCH, MICRO, V7-1C17E9 2
24 35117 W/A STRIKE, LID LATCH, LH 1
25 35222 SPRING, ELEMENT, 1200 2
26 13-0350 O-RING, .12 X 1.12 X 1.37 BUNA-N 4
27 35106 ISOLATOR, ELECTRODE 2
28 35105 CONNECTOR, ELECTRODE 2
29 30112 WASHER, FLAT, 1/4, SS 4
30 (REF) WIRE LUG, #12 N/A
31 35198 DISCONNECT, PROCESS GAS 1
32 35201 SPRING, COMP, 70398S 1
33 35197 SPRING STOP, PROCESS GAS 1
34 35335 HEX NUT, 1/4-28, BRASS 4
35 35107 GUARD, ELECTRODE 2
36 31378-33 SCREW, SHC, #6-32 X 1.50, STL 8
37 35321 INSULATOR, ELECTRODE NUT 2
