5-18
5.4.2 CONTROL SYSTEM INSTALLATION
ITEM NUMBER
PART NUMBER DESCRIPTION QTY
1 35079 W/A ENCLOSURE BOX 1
2 35118 PANEL, ELEC. BOX 1
3 22-1490-1 PUSH BUTTON ACTUATOR, EMER 1
4 12-0180 SWITCH, RED PUSH BUTTON 1
5 22-3420 GREEN LIGHT IDI 1052QC5 1
6 35276 DIGITAL VACUUM GAGE 1
7 30032 NUT, HEX, #10-32 12
8 33577-01 WASHER, FLAT, #10 14
9 500-A212 SONALERT #SC110 1
10 12-0190 SWITCH, BLACK PUSH BUTTON 2
11 32653-03 SCREW, PAN HD, #10-32 X .50 2
