UM2408 Rev 2 45/51
UM2408 Hardware layout and configuration
50
1. PC9 = SDMMC_D1 / SAI2_EXTCLK
2. PG10 = D49 / SMPS_SW
3. PG8 = D50 / SMPS_V1
4. PB2 = D27 / D72
5. PB5 = D11 (H745ZI / H755ZI) / D22 / D70
6. PB14 = D65 / LED_RED
7. PE2 = D31 / D56
8. PE6 = D59 / D38
9. PD10 = D64 / USB_FS_PWR_EN (H745ZI / H755ZI)
10. PB13 = D18 / RMII_TXD1 (H745ZI / H755ZI)
11. PB3 = D23 / SWO
12. PG9 = D8 / SMPS EN
13. PA2 = A8 / RMII_MDIO (H745ZI / H755ZI)
14. PG12 = D7 / SMPS_PG
15. PA8 = D6 / USB_SOF / MCO1
