STA-RITE MPE - Page 14

14
MPEA6G-207L
MPEA6F-206L MPE6F-207L MPEAA6G-208L
MPEA6D-204L MPEA6E-205L MPE6E-206L MPEA6YG-207L MPE6G-208L
Key Part MPE6C-204L MPE6D-205L MPRA6F-206L MPE6YF-207L MPEAA6YG-208L
No. Description Qty. MPRA6D-204L MPRA6E-205L MPRA6YF-206L MPRA6G-207 MPE6G-208L
2 Screw #10-32x1/2" 1 U30-692SS U30-692SS U30-692SS U30-692SS U30-692SS
3 Bonding Lug 1 U17-568 U17-568 U17-568 U17-568 U17-568
4 Slinger 1 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
5 Seal Plate 1 C3-184P C3-184P C3-184P C3-184P C3-184P
6 Seal Plate Cord Ring 1 U9-373 U9-373 U9-373 U9-373 U9-373
7 Shaft Seal 1 37400-0027 37400-0027 37400-0027 37400-0027 37400-0027
8 Impeller 1 C105-236P C105-236PB C105-236PC C105-236PDA C105-236PEA
8A Gasket 1 – – – 33455-1047 33455-1047
8B Impeller Lock Screw 1 – – – 37337-6080 37337-6080
9 Diffuser 1 C1-270PB C1-270PC C1-270P C1-270P C1-270P
10 Diffuser O-Ring 1 U9-374 U9-374 U9-374 U9-374 U9-374
11 Tank and Trap Body (Only) 1 C76-71P C76-71P C76-71P C76-71P C76-71P
12 Trap Lid and Ring Assembly 1 17307-0111 17307-0111 17307-0111 17307-0111 17307-0111
13 Trap Cover O-Ring 1 35505-1440 35505-1440 35505-1440 35505-1440 35505-1440
14 Trap Basket 1 C8-58P C8-58P C8-58P C8-58P C8-58P
15A Drain Plug 2 U178-920P U178-920P U178-920P U178-920P U178-920P
15B Mounting Screw 5/16-14x5/8" 2 U30-919SS U30-919SS U30-919SS U30-919SS U30-919SS
16 Base - Plastic 1 C4-77P C4-77P C4-77P C4-77P C4-77P
17 Motor Pad - for Plastic Base 1 C35-45 C35-45 C35-45 C35-45 C35-45
18 Screw #8-32x7/8" Rd. Hd. 7 U30-542SS U30-542SS U30-542SS U30-542SS U30-542SS
19 Lock Washer #8 Ext. Tooth 7 U43-21SS U43-21SS U43-21SS U43-21SS U43-21SS
20 Flat Washer 3/8" 6 U43-62SS U43-62SS U43-62SS U43-62SS U43-62SS
21 Lock Washer 3/8" 6 U43-12SS U43-12SS U43-12SS U43-12SS U43-12SS
22 Nut 3/8-16 Hex 6 U36-38SSW U36-38SSW U36-38SSW U36-38SSW U36-38SSW
23 Cap Screws 3/8-16x1-1/4" Hex. (LS Suffix) 2 – – U30-75SS U30-75SS U30-75SS
24 Cap Screws 3/8-16x1" Hex. 4 U30-74SS U30-74SS U30-74SS U30-74SS U30-74SS
• Nameplate 1 32155-4071 32155-4071 32155-4071 32155-4071 32155-4071
• Tag, “CAUTION This pump equipped with 1 61002-0012 61002-0012 61002-0012 61002-0012 61002-0012
mechanical shaft seal…”
• Voltage Sticker 1 U27-153 U27-153 U27-153 U27-68 U27-68
• Tag, “WARNING/CAUTION/Instructions...” 1 C63-12 C63-12 C63-12 C63-12 C63-12
REPAIR PARTS LIST
DYNA-PRO™ POOL PUMP
1/2 through 2-1/2 HP Models Single Speed and Two Speed
• Not illustrated.
