STA-RITE MPE - Page 8

8
TABLE I - RECOMMENDED CIRCUIT BREAKER AND WIRING DATA
Serv. to Motor - Dist. in Ft. (M)
Motor Branch CB Max Load Voltage/ 0-100' 101-200' 201-300'
HP Rating Amps Amps Hz/Phase (0-30) (30-60) (60-90)
MPRA SERIES – SINGLE SPEED
3/4 20/15 13.4/6.7 115/230/60/1 12/14(3/2) 10/14(5.5/2) 8/14(8.4/2)
1 20/15 15.3/7.6 115/230/60/1 12/14(3/2) 8/14(8.4/2) 6/14(14/2)
1-1/2 25/15 19.2/9.6 115/230/60/1 10/14(5.5/2) 8/14(8.4/2) 6/12(14/3)
2 20 12.0 230/60/1 14(2) 14(2) 12(3)
MPEA SERIES – SINGLE SPEED
3/4 15/15 11.0/5.5 115/230/60/1 14/14(2/2) 10/14(5.5/2) 8/14(8.4/2)
1 20/15 13.8/6.9 115/230/60/1 12/14(3/2) 10/14(5.5/2) 8/14(8.4/2)
1-1/2 25/15 16.0/8.0 115/230/60/1 12/14(3/2) 8/14(8.4/2) 6/14(14/2)
2 15 10.4 230/60/1 14(2) 14(2) 12(3)
2-1/2 15 11.2 230/60/1 14(2) 14(2) 12(3)
MPRA SERIES – TWO SPEED
1-1/2 – 1/4 15 9.2/2.5 230/60/1 14(2) 14(2) 12(3)
MPEA SERIES – TWO SPEED
2 – 1/4 15 10.0/3.0 230/60/1 14(2) 14(2) 12(3)
2-1/2 – 1/2 15 11.3/3.3 230/60/1 14(2) 12(3) 12(3)
MPE SERIES – SINGLE SPEED
1/2 15/15 11.0/5.5 115/230/60/1 14/14(2/2) 10/14(5.5/2) 8/14(8.4/2)
3/4 20/15 13.8/6.9 115/230/60/1 12/14(3/2) 10/14(5.5/2) 8/14(8.4/2)
1 25/15 16.0/8.0 115/230/60/1 12/14(3/2) 8/14(8.4/2) 6/14(14/2)
1-1/2 15 10.4 230/60/1 14(2) 14(2) 12(3)
2 15 11.2 230/60/1 14(2) 14(2) 12(3)
MPE SERIES – TWO SPEED
1-1/2 – 1/4 15 10.0/3.0 230/60/1 14(2) 14(2) 12(3)
2 – 1/3 15 11.3/3.3 230/60/1 14(2) 12(3) 12(3)
AWG
Wire
Size
(mm
2
)
}
AWG
Wire
Size
(mm
2
)
}
AWG
Wire
Size
(mm
2
)
}
AWG
Wire
Size
(mm
2
)
}
AWG
Wire
Size
(mm
2
)
}
