Sight Glass Adaptor – 1
1
⁄2" NPT & Hose ..............................Order #14962-0012
Sight Glass Adaptor – 1
1
⁄2" NPT ...........................................Order #14962-0013
• Male Adaptor – 1
1
⁄2" NPT to 1
1
⁄2" ID Hose............................Order #U78-767P
• Not illustrated.
Performance Curves – Multi-Port Valves
1
1
⁄2" Side Mount Valve with Piping
2" Side Mount Valve with Piping
Sight Glass, Sight Glass Adaptors
0
10 20
30 40 50 60
70
80
4
8
12
16
20
24
0
10
20
30
40
50
Capacity (GPM)
P.S.I. Loss
Pressure Drop (Feet)
2547 0796
0
20 40
60 80 100 120
140
160
4
8
12
16
20
24
0
10
20
30
40
50
Capacity (GPM)
P.S.I. Loss
Pressure Drop (Feet)
2548 0796
2840 0597
2841 0597
