GENERAL
Inspect valve upon receipt and file claim with carrier if parts are damaged or
missing.
Valve may be used with Sta-Rite DE or sand filters. See Table I.
Mating half of unions are on filters shown on Table I.
Connecting Multi-Port Valve To Filter System
For filters listed below, select correct valve clamp connector kit from the
chart. Use with valves 14964-0014, 14962-0105, 14971-0000 (purchase
separately).
TABLE I – Filter and connector kits to use with valves.
NOTICE: Valve WC212-138B for use with HRP36 filter
only
.
NOTICE: WC212-143P, WC212-144P, and WC212-150PN valves are fur-
nished with union connections, matching the connections of the filter ports.
DO NOT use pipe sealants on union collar (nut).
Use care before assembly not to damage union sealing surfaces or O-Ring.
Install union O-Rings in groove; tighten union collar hand tight.
FOR SLIP FITTINGS: Use correct solvent/cement when fitting piping or
adapters to slide valve. The valve body is ABS plastic, thus any good quality
ABS to PVC solvent can be used, such as Weld-On #793 or #710. Use P70
(purple) primer on PVC components only. Allow a minimum of four hours
drying time prior to pressure testing or operation. If ABS adapters are glued
into valve ports in lieu of PVC fittings, use Weld-On Solvent #771, #1707 or
#773.
To avoid serious personal injury or property damage, follow
cement manufacturer’s instructions exactly.
NOTICE: FOR THREADED FITTINGS: Use Plasto-Joint Stik
1
only. Other sub-
stances may degrade plastic and create poor joints and leaks. Do not over-
tighten.
1
Lake Chemical Co., Chicago, IL
Valve No.
14971-0000 Valve No.
WC212-150PA 14964-0014
Use with: Use with:
Filter Kit Filter Kit
DEP36 DES25
DEP51 DES36
DEP83 24750-0331
HRS16
DES51 HRS20
DES60 24750-0341
DEP36
HRP20
HRP24 HRP20
HRP30 HRP24 24750-0624
HRS24 HRS24
DES25
DES36
24750-0624
HRS16
HRS20
To Next Page
