Topmount Multiport Valve Assembly – 1
1
⁄2"
Model 14962-0105
REPAIR PARTS LIST
STA-RITE
STA-RITE IND., INC.
WATERFORD, WI.
53185
USA
R
E
C
I
R
C
U
L
A
T
E
B
A
C
K
W
A
S
H
C
L
O
S
E
D
W
I
N
T
E
R
I
Z
E
W
A
S
T
E
F
I
L
T
E
R
R
I
N
S
E
11
8
9
12
16
17
13
12
18
14
15
1
1
2
5
6
7
3
4
10
2837 0597
Key Part Kit
No. Description Qty. Number Number
1 Plug with Gasket 1 14962-0017
2 Body Assembly 1 14962-0037S
3 Hex Nut,
1
⁄4-20 S.S. 6 35407-4297
4 Screw,
1
⁄4-20x1
1
⁄4" S.S. 6 37337-3056
5 Square Ring, BUNA-N 1 14962-0021
6 Pressure Gauge – 0-60 PSI 1 15060-0000T
7 Bolt,
3
⁄8-16x1" S.S. 8 U30-74SS
8 Washer, Flat
3
⁄8" Plain S.S. 8 38907-3192
9 Handle 1 14962-0123
10 Dowel Pin,
5
⁄16x2
1
⁄2" S.S. 1 35857-0021 14962-0029
11 Label – Swimquip Logo 1 WC27-91
12 Washer, Celcon 2 14962-0005
13 O-Ring, Parker #2-216, BUNA-N 1 35505-1228
14962-0035
14 Spring, Compression 1 14962-0011
15 O-Ring, Parker #2-255 1 35505-1272
16 Operating Decal 1 32155-4122
14962-0041
17 Valve Cover 1 14962-0028
18 Plug and Cover Assembly 1 77704-0102
}
}
}
