Stairmaster Zephyr - Assembly Parts List

ASSEMBLY PARTS LISTING
PAGE 2
A
A
SSEMBLY
SSEMBLY
P
P
ARTS
ARTS
L
L
IST
IST
Item # Part Number Description QTY.
1
060-0038
Base Frame Assembly 1
2 060-0001 Front Stabilizer Assembly 1
3 060-0002 Rear Stabilizer Assembly 1
4
060-0003
Sensor Cable 1
5 060-0004 Console 1
6 060-0005 Console Mast 1
7
060-0006
Adjustable Seat Slider 1
8
060-0007
Seat Post 1
9 1
Seat
060-0008
10 060-0009 Seat Slider Adjustment Knob 1
11 060-0010 Seat Back Post 1
12 060-0011 Seat Post Adjustment Knob 1
13
060-0012
Seat Back Bracket 1
14 060-0013 Seat Back Pad 1
15 060-0014 Connecting Arm (Preinstalled) 2
16 060-0015 Left Pivot Arm Assembly 1
17 060-0016 Right Pivot Arm Assembly 1
18 060-0017 Left Foot Rest 1
19 060-0018 Right Foot Rest 1
20 060-0019 Left Pedal 1
21 060-0020 Right Pedal 1
22 060-0021 (Large) Carriage Bolt M8 x 50 Length 4
23 060-0022 (Large) Spring Washer 20 x 8.5 x 1.5t 12
24 060-0023 (Large) Acorn Nuts M8 12
25 060-0024 (Small) Carriage Bolts M6 x 35 Length 2
26 060-0025 Pan Head Screw 4
27 060-0026 Button Head Allen Bolt M8 x 40 Length 2
28 060-0027 Button Head Allen Bolt M8 x 12 Length 2
29 060-0028 Button Head Allen Bolt M8 x 15 Length 6
30 060-0029 Pivot Bolt M8 x 35 Length 2
31 060-0030 Flat Washer 20 x 8.5 x 1.5t 2
32 060-0031 Nylon Nut M8 2
33 060-0032 (Small) Spring Washer 10 x 6.5 x 1.5t 2
34 060-0033 (Small) Acorn Nut M6 2
35 060-0034 Cage, Water Bottle 1
36 060-0035 Water Bottle 1
