TROUBLE SHOOTING GUIDE
Sensor Wires
Allen Wrench
Wrench
Scissor
Bungee
Cord Tie
Wrench
Screw
Strap
3. 4.
1. 2.
Disconnect the Sensor Wires. Remove the Meter
Post Assembly hardware with Wrenches and
remove the Meter Post Assembly.
Detach the Bungee Cord from the Bungee Pulley
at the bottom of rower to release the Bungee
Cord tension. Unhook the Bungee Cord from the
hook locketed at the bottom of rower. Cut o the
Bungee Cord as close as possible to the Bungee
Cord Tie.
Remove all the Screws from the Right Cover and
remove Right Cover.
Slowly pull out the current Strap. Carefully rotate
the Strap/Bungee Pulley to release the Loop Pad
on the Strap.
The following are instructions for removing
the current STRAP(95) and installing the new
STRAP(95).
Please take a moment to read the caution posted
on the rower inside the covers.
17
STRAP REPLACEMENT
Over time, the STRAP(95) may become frayed or worn. If your Wave Water Rowing Machine 1450
is within the 90 day warranty, a replacement STRAP(95) is available by contacting Stamina Customer
Care at customer.care@staminaproducts.com. If your Wave Water Rowing Machine 1450 is not under
warranty, you can purchase a replacement STRAP(95).
Bungee
Pulley
To Next Page
