Bungee
Cord
Bungee Cord
10.9.
7. 8.
Bungee
Pulleys
Sensor Wires
Allen Wrench
Wrench
Wrench
Screw
Attach the Meter Post Assembly back to the
frame. Connect the Sensor Wires.
Attach the Right Cover back to the frame. Place
the Handlebar on the Handlebar Holder.
Rotate the Strap/Bungee Pulley enough to place
the Handlebar up against the Strap Pulley. Run
the Bungee Cord through the Bungee Pulleys.
Secure the Bungee Cord to the frame with the
Cable Ties as illustrated.
Bungee Pulley
Strap Pulley
Place the Handlebar
at this position.
Cable Ties
Strap
Loop Pad of the
Strap facing down.
5.
Make sure the Loop Pad of the new Strap is
facing down, run the Strap through the Protection
Ring, then run over and around the Strap Pulley.
Strap Pulley
Strap
Loop Pad of the Strap
6.
Run the Strap through the Strap Pulley, turn it
90 degrees on the Idler Roller, then attach to the
Strap/Bungee Pulley with the Loop Pad.
Strap/
Bungee Pulley
Strap Pulley
Idle Roller
