Stanley BR67 Safety, Operation & Maintenance

6 | BR67 User Manual
T-Handle Parts Illustration - Detail E
ITEM P/N DESCRIPTION
1
06687 Valve Cap
2
04052 O-ring*
3
01772 O-ring
4
06684 Sintered Filter
5
22768 Seal Spacer
6
06688 Retaining Ring
7
04051 Charging Valve
8
00844 Roll Pin
9
04053 Trigger
10
10180 Gas Under Pressure Decal
11
22891 Roll Pin
12
02494 Handle Grip
13
04055 Washer
14
04056 Rod Wiper*
15
00293 O-ring*
16
04057 Bushing
17
01362 O-ring*
18
04077 Valve Spool
19
04058 Spring
20
04350 Orifice Plug
21
04049 Breaker Handle
22
01652 Hose
23
03972 Female Coupler
24
02324 Cap - Models BR67120D, BR6713016
25
03288 Cap - Models BR67120D, BR6713016
26
03973 Male Coupler
27
04054 O-ring*
28
04060 Accumulator Cylinder
29
04059 Accumulator Diaphragm
30
04061 Accumulator Chamber
31
04062 Backup Washer
32
04063 Rod Seal*
33
04064 Seal Retainer Washer
34
74667 Tool Name Tag
35
04071 Side Rod
36
73025 Snap-on Filler - Model BR67120
37
74832 STANLEY Logo Decal
38
04075 Side Rod Nut
39
Depends on
Model
Breaker Foot (See Detail G & H)
40
04070 Piston
41
04054 O-ring*
42
04066 Automatic Valve Body
43
04571 Push Pin
44
04065 Automatic Valve
45
07890 Roll Pin
46
04067 Push Pin
47
04069 Flow Sleeve
48
04054 O-ring*
T-Handle Parts Illustration - Detail E
ITEM P/N DESCRIPTION
49
04068 Flow Sleeve Tube
50
04596 Seal Kit (Not Shown) - * In Seal Kit
