BR67 User Manual | 7
Anti Vibration Handle Parts Illustration - Detail F
ITEM P/N DESCRIPTION
1
07628 Hex Head Cap Screw
2
26450 Top Plate
3
20511 Lever
4
28369 Handle
5
02494 Handle Grip
6
20500 Roll Pin
7
58529 Handle
8
20541 Spring
9
20498 Spring
10
20508 Pivot Screw
11
26596 Accumulator Valve Block
12
58526 Trigger - Models BR6717801A, BR6717801AA,
BR6717802AA
20502 Trigger - Models BR67125, BR67135,
BR6713516,
13
07624 Roll Pin - Models BR6717801A, BR6717801AA,
BR6717802AA
14
66828 Spring - Models BR6717801A, BR6717801AA,
BR6717802AA
15
58527 Trigger Lock - Models BR6717801A,
BR6717801AA, BR6717802AA
16
11207 Circuit Type “D” Decal
17
01652 Hose
18
03972 Female Coupler
19
03973 Male Coupler
20
24067 Retaining Ring
21
04055 Washer
22
04056 Rod Wiper*
23
00293 O-ring*
24
26451 Bushing
25
01362 O-ring*
26
20515 Valve Spool
27
04058 Spring
28
06891 O-ring*
29
31067 Spacer Plug
30
74668 Tool Name Tag
31
04070 Piston
32
04054 O-ring*
33
04066 Automatic Valve Body
34
04571 Push Pin
35
07890 Roll Pin
36
04065 Automatic Valve
37
04067 Push Pin
38
04069 Flow Sleeve
39
04054 O-ring*
40
04068 Flow Sleeve Tube
41
04071 Side Rod
42
74832 STANLEY Logo Decal
43
73025 Snap-on Filler
44
04075 Side Rod Nut
Anti Vibration Handle Parts Illustration - Detail F
ITEM P/N DESCRIPTION
45
11208 Hex Shank Length Decal
46
Depends on
Model
Breaker Foot (See Detail G & H)
47
28409 Composite Safety Sticker
48
66654 Sound Power Decal
49
28322 CE Decal
50
04064 Seal Retainer Washer
51
04063 Rod Seal*
52
04062 Backup Washer
53
26448 Spacer
54
16732 O-ring*
55
26452 Sintered Filter
56
04795 O-ring*
57
26574 Accumulator Diaphragm
58
26449 Accumulator Plug
59
20499 Charging Valve
60
07493 Plug
61
04596 Seal Kit (Not Shown) - * In Seal Kit
To Next Page
