22 ► CS05/CS06 User Manual
CS05/CS06 PARTS LIST
ITEM
NO.
PART
NO. QTY DESCRIPTION
1 00753
09622
8 CAPSCREW
CAPSCREW U/W MODEL
2 07636
08202
1 NAME TAG—CS06
NAME TAG—CS05
3 28323 1 CE DECAL (CE ONLY)
4 07652 1 REAR GEAR HSG ASSY (7–9 GPM)
07834 1 REAR GEAR HSG ASSY (4–6 GPM)
5 00289 2 DOWEL PIN
6 04041 4 BUSHING
7 00020 1 O-RING
8 07612 1 IDLER SHAFT
9 04106
07832
2 DRIVE GEAR (7–9 GPM)
DRIVE GEAR (4–6 GPM)
10 — — NO ITEM
11 00038
00788
1 NUT
NUT U/W MODEL
12 01362 1 O-RING
13 02921 1 AUTOMATIC OILER
14 17784 1 SOUND POWER LEVEL. DECAL
(CE ONLY)
15 06971
07724
1 LOCKNUT
LOCKNUT U/W MODEL
16 07620
07714
1 BAR ADJUSTMENT NUT
BAR ADJUSTMENT NUT U/W MODEL
17 11354 1 OC/CC DECAL (NOT ILLUSTRATED)
18 07632
07723
1 SCREW
SCREW U/W MODEL
19 00144
00230
1 CAPSCREW
CAPSCREW U/W MODEL
20 01116 1 BUCKING CLEAT
21 02649 2 HANDLE BAR RETAINER
22 07611 1 HANDLE BAR
23 02634 3 WASHER
24 00429
09277
1 NUT
NUT U/W MODEL
25 07473 1 HAND GUARD
26 13907 1 WARNING DECAL (KICKBACK)
27 12412 1 WARNING DECAL (ELECTRIC)
28 28409 1 COMPOSITE SAFETY DECAL (CE
ONLY)
29 07628
02446
3 CAPSCREW
CAPSCREW U/W MODEL
30 66577 1 CHAIN GUIDE PLATE-INSIDE
31 08347 1 SAW BAR 12 IN.
07638 1 SAW BAR 15 IN.
07639 1 SAW BAR 20 IN.
32 08348 1 SAW CHAIN – 12 IN.
07641 1 SAW CHAIN – 15 IN.
07642 1 SAW CHAIN – 20 IN.
ITEM
NO.
PART
NO. QTY DESCRIPTION
33 66578 1 CHAIN GUIDE PLATE-OUTSIDE
34 07618 1 CHAIN GUARD
35 07631
07722
2 NUT
NUT U/W MODEL
36 00453
00808
1 NUT
NUT U/W MODEL
37 07617 1 WASHER
38 07629 1 RIM SPROCKET
39 07616 1 SPROCKET ADAPTER
40 06635 1 RET RING
41 00335
07720
1 BALL BEARING
BALL BEARING U/W MODEL
42 04746 1 AUTOMATIC OILER DECAL
43 04539 1 WASHER
44 07623 1 CHAIN CATCHER
45 07630 2 STUD
46 02688
02764
1 CAPSCREW
CAPSCREW U/W MODEL
47 04037 1 SHAFT SEAL
48 07615 1 SEAL BACK-UP WASHER
49 04856 1 RETAINING RING
50 04044 2 NEEDLE ROLLER
51 07613
07710
1 DRIVE SHAFT
DRIVE SHAFT U/W MODEL
52 16070 1 RETAINING RING
53 10536 1 SELECTOR SCREW
54 00026 1 O-RING
55 07627 1 O-RING
56 00072
00875
1 ROLL PIN
ROLL PIN U/W MODEL
57 07603 1 SAFETY CATCH
58 07602
07715
1 SPRING
SPRING U/W MODEL
59 34093 1 TRIGGER CASTING
60 03972 1 COUPLER, FEMALE
61 03973 1 COUPLER, MALE
62 28234 2 HOSE
63 01605 2 O-RING
64 07693
07713
1 VALVE HANDLE ASSY
VALVE HANDLE ASSY U/W MODEL
65 07624
07718
1 ROLL PIN
ROLL PIN U/W MODEL
66 03009
03278
2 ROLL PIN
ROLL PIN U/W MODEL
67 11207 1 CIRCUIT TYPE D DECAL (CE ONLY)
68 10535 1 ON/OFF VALVE SPOOL
69 07626 1 O-RING
70 07609 2 SPRING WASHER
