19
ENGLISH
(Original instructions)
Problem Possible Cause Solution
Blade binds, jams or
shakes
Saw blade damaged Replace blade
Dull blade Replace or sharpen
blade
Improper blade Replace blade
Warped blade Replace blade
Saw vibrates or
shakes
Saw blade damaged Replace blade
Saw blade loosened Tighten arbor bolt
Saw not properly fastened
down
Fasten saw to bench,
stand or table
Work piece not properly
supported
properly support or
clamp work piece
Laser line projection
is hard to see
Light in work area is too
bright
Move the mitre saw
to a work area with
proper light
Saw dust on the laser lens Clean laser lens with
a soft, dry brush
Protecting the environment
Z
Separate collection. This product must not be
disposed of with normal household waste.
Should you nd one day that your Stanley Fat Max product
needs replacement, or if it is of no further use to you, do not
dispose of it with household waste. Make this product avail-
able for separate collection.
z
Separate collection of used products and packag-
ing allows materials to be recycled and used again.
Re-use of recycled materials helps prevent
environmental pollution and reduces the demand
for raw materials.
Local regulations may provide for separate collection of elec-
trical products from the household, at municipal waste sites or
by the retailer when you purchase a new product.
Stanley Europe provides a facility for the collection and
recycling of Stanley Fat Max products once they have reached
the end of their working life. To take advantage of this service
please return your product to any authorised repair agent who
will collect them on our behalf.
You can check the location of your nearest authorised repair
agent by contacting your local Stanley Europe ofce at
the address indicated in this manual. Alternatively, a list of
authorised Stanley Europe repair agents and full details of our
after-sales service and contacts are available on the Internet
at: www.2helpU.com
Technical data
FME721
Motor 230V~50Hz, 1500W S6 20%
5min
Speed 5000RPM
Blade 216mm (40 tooth) carbide
tipped
Laser Class ll
Laser wavelength 650nm
Laser outpower <1mW
Net weight 16.6kg
Cutting capacity 6.2 x 30.5cm crosscut at 0º
mitre, 0º bevel
6.2 x 21.5cm mitre at 45º mitre,
0º bevel
3 x 30.5 cm bevel at 0º mitre,
45º bevel
3 x 21.5cm compound at 45º
mitre, 45º bevel
L
pA
(sound pressure) 99dB(A), Uncertainty (K) 3dB(A)
L
WA
(sound power) 111dB(A), Uncertainty (K) 3dB(A)
Vibration total values (triax vector sum) according to EN 61029:
Vibration emission value (a
h
) 4.8m/s
2
, uncertainty (K) 1.5 m/s
2
EC declaration of conformity
MACHINERY DIRECTIVE
%
FME721 Sliding Compound Mitre Saw
Stanley Europe declares that these products described under
"technical data" are in compliance with:
