26
Item
No.
Part No. Qty Description
1 65294 1 Muffler Kit
2 62292 2 Hex Washer Head Screw
3 --- - No Item
4 36918 1 Honda Engine
5 56656 1 Coupling
6 07819 1 Square Key
7 07860 2 Capscrew, 3/8-16 x 1-1/4
8 31765 1 Pressure Switch
9 12787 4 Flange Nut, 5/16
10 24287 1 Clamp
11 59076 1 Bushing
12 20990 1 Key
13 59103 1 Blower Hub
14 00753 3 Capscrew, 10-24
15 40080 1 Filter Assy
16 43687 1 Capscrew, M8 x 16
17 64937 1 Grip Plate
18 51292 1 Std Thread Union
19 17821 4 Button Head HS, 1/4 x 20
20 60945 2 Washer, 1/4 in. ID
21 15476 2 Capscrew, 1/2 -20 UNC
22 59080 1 Front Grille
23 59091 1 Cooler
24 07860 2 Capscrew, 3/8-16
25 59077 1 Hydraulic Tank
26 62296 2 Weather Strip
27 62303 1 Blower Wheel
28 59074 4 Hex Flange Bolt, 1/4 -20
29 65082 1 Engine Controller
30 65058 1 Hex Flange Bolt
31 58897 1 Frame Base Weldment
32 58918 2 Wheel & Tire
33 58917 1 Axle
34 04134 1 Pump, Single
35 07810 1 Fuel Cap
36 60920 1 Grommet
37 59078 1 Fuel Tank
38 04303 1 Battery
39 60921 1 Battery Cover
40 15476 1 Capscrew, 1/4-20
41 60945 1 Washer, 1/4
42 40433 9 Hex Flange Bolt, 5/16
43 58942 4 Hex Flange Bolt, 5/16
44 01459 4 Lockwasher, 3/8
45 58975 2 Foot
Item
No.
Part No. Qty Description
46 18893 4 Flang Nut, 3/8-16
47 58976 4 Hex Flange Bolt, 3/8-16
48 31240 2 Retaining Ring
49 21318 2 Washer, 3/4
50 59083 1 Blower Housing
51 56655 1 Pump Mount
52 60919 1 Fuel Elbow
53 62385 2 Stud
54 371503 1 Nut
55 60972 2 Hex Flange Bolt, M6 x 15
56 49174 1 Screw, M8 x 30
57 62185 1 Spring
58 62179 1 Choke Pivot Weldment
59 60945 1 Washer, 1/4 inch ID
60 60962 1 HSHCS 1/4-20 x 1/2 inch
61 62181 2 Link Retainer
62 62184 1 Choke Link
63 62183 1 Spring
64 62180 1 Rotary Actuator
65 64990 1 Spring, Torsion
66 65072 1 Link Retainer
67 62182 1 Throttle Link
68 ----- -- No Item
69 64991 1 Screw, M8 x 12
70 56709 1 Cable Clamp
71 62177 1 Actuator Weldment
72 60970 2 Hex Flange Bolt, M5 x 10
73 60971 2 Flange Nut, 8-32
74 60948 1 Stub Shaft
75 60949 3 Washer
76 60950 3 HSHCS, M8 x 55
77 60953 2 Hex Flange Bolt, 1/4-20 x 1 inch
78 60957 1 Rectifier Bracket
79 --- 1 Rectifier (Part of Engine Assy)
80 59095 2 Flange Nut, 1/4-20
81 37294 1 Wire Harness
82 --- - No Item
83 62404 1 Mag Kill Wire
84 62405 1 Fuel Shutoff Wire
85 --- - No Item
86 --- - No Item
87 62325 1 Heat Shield
88 21714 2 Handle Bumper
FIGURE 1A. HONDA ENGINE PARTS LIST
