Stanley IntelliLaser Pro User Manual

1. Laser plane in the stud detection mode is
always on, a laser plane icon is also shown on the
LCD. It can be turned off by pressing “ ” button
once.
2. Laser plane can also be turned on individually by
pressing “ ” button once or pressing again to
turn it off.
3. The Laser plane will be auto - off after 1 hour.
4. The projected laser plane will coincide with
stud edge indicator.
5. The level vials are aligned to the laser plane.
When the bubble is centered, the laser plane
will be vertical/horizontal (depending on vial
used).
Operating Tips
IMPORT
ANT SAFETY NOTICE
Insure proper detection of live wires ALWAYS
hold the Intelli
LLaasseerr
™
PPrroo
in the handle area
only. Grasp between fingers and thumb while
maintaining contact with your palm.
–11–
Laser Aperture
Illustration 13
Vials
Laser Plane
114C IM 14Aug06 8/14/06 7:40 PM Page 12

Stanley IntelliLaser Pro Specifications

General

Power Source	Battery
Battery Type	AA
Laser Wavelength	635 nm
Self-Leveling Range	+/- 4 degrees
Self-Leveling	Yes
Warranty	1 year
Accuracy	+/- 1/8 inch at 30 feet
Battery Life	Up to 20 hours
Outdoor Use	Yes, with detector
