Stanley ProSet XT1 Blind Rivet Tool - Page 3

90˚
6
Figure 3
Figure 4
Figure 6
Figure 5
3 METERS MAXIMUM
STOP COCK
(USED DURING MAINTENANCE OF FILTER/
REGULATOR OR LUBRICATION UNITS)
TAKE OFF POINT FROM SUPPLY
MAIN SUPPLY DRAIN POINTPRESSURE REGULATOR
AND FILTER (DRAIN DAILY)
