Star Max 648TF - Parts List

11
PARTS LIST June 13, 2012, Rev -
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 1
INCLUDE MODEL AND SERIAL NUMBER OF 3
Some items are included for illustrative purposes only and in certain instances may not be available.
Star International Holdings, Inc. Company
2M-Z16008 Star-Max Gas Griddles
Model: 615, 624, 636, 648 Star-Max Gas Griddles
Fig No Part No Qty Description Application
1
G3-615315
1
GRIDDLE PLATE ASSEMBLY
615MF
G3-615316 615TF
G3-624320 624MF
G3-624321 624TCHSF
G3-624322 624TF, 624TSPF
G3-624323 DIVIDED PLATE ASSEMBLY 624MF-DIV
G3-636316
GRIDDLE PLATE ASSEMBLY
636MF
G3-636317 636TCHSF
G3-636318 636TF, 636TSPF
G3-648320 648MF
G3-648321 648TCHSF
G3-648322 648TF, 648TSPF
G3-648323 648TF-TFR
G3-648324 648TF-TFL
2
G3-615304
1 CHUTE ASSEMBLY
ALL 615
G3-624304 ALL 624, 636, 648
3 G5-Z4817 1 FLUE DIVIDER ALL 636, 648
4
G3-Z5906
1 FLUE
615MF, 615TF
G3-Z5916 624MF, 624TF, 624TSPF, 624TCHSF
G3-Z5926 636MF, 636TF, 636TSPF, 636TCHSF
G3-Z5936 648MF, 648TF, 648TSPF, 648TCHSF
5 G3-Z5945 2 SIDE PANEL ALL
6 G3-624302 1 SIDE LINER ASSEMBLY LEFT ALL
7
G3-Z5951
1 REAR PANEL
615MF, 615TF
G3-Z5953 624MF, 624TF, 624TSPF, 624TCHSF
G3-Z5955 636MF, 636TF, 636TSPF, 636TCHSF
G3-Z5957 648MF, 648TF, 648TSPF, 648TCHSF
8 G3-624303 1 SIDE LINER ASSY RIGHT ALL
9
G3-Z5909
1 BOTTOM
615MF,615TF
G3-Z5919 624MF, 624TF, 624TSPF, 624TCHSF
G3-Z5929 636MF, 636TF, 636TSPF, 636TCHSF
G3-Z5939 648MF, 648TF, 648TSPF, 648TCHSF
10 2A-Z5942 4 FOOT ALL
11 2C-8823 Various SCREW #8 x 3/8 ALL
12 G3-Z6036 2 DRAWER SLIDE ALL
13 G3-Y7046 1 GREASE DRAWER ALL
15
2M-Z15449
1/2/3/4
KNOB LABEL MAN LG 615MF / 624MF / 636MF / 648MF
2M-Z15450 LABEL GAS T-STAT LG 615TF / 624TF / 636TF / 648TF
2M-Z16011 2/3/4
KNOB LABEL GAS-TSTAT
PILOT
624TSPF/ 624TCHSF/ 636TSPF/ 636TCHSF/
648TSPF/ 648TCHSF
16
G3-Z15791
1/2/3/4
KNOB ASSY LG GAS KEYR 615TF / 624TF / 636TF / 648TF
I4-Z15484 KNOB ASSY LG GAS KEYB
615MF / 624MF / 636MF / 648MF
2/3/4
624TSPF / 636TSPF / 648TSPF
624TCHSF / 636TCHSF / 648TCHSF
