Star Max 648TF - Page 12

12
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 2
INCLUDE MODEL AND SERIAL NUMBER OF 3
Some items are included for illustrative purposes only and in certain instances may not be available.
Star International Holdings, Inc. Company
2M-Z16008 Star-Max Gas Griddles
Model: 615, 624, 636, 648 Star-Max Gas Griddles
Fig No Part No Qty Description Application
17 2M-Z15804 1 STAR-MAX LOGO ALL
18
G3-Z15797
1 FRONT PANEL
615MF
G3-Z15798 615TF
G3-Z15799 624MF
G3-Z15806 624TF, 624TSPF, 624TCHSF
G3-Z15807 636MF
G3-Z15808 636TF, 636TSPF, 636TCHSF
G3-Z15809 648MF
G3-Z15810 648TF, 648TSPF, 648TCHSF
19 2C-8477 3 CLIP .125 PO STL PHOS ALL
20 G3-Z5946 1/2/3/4 BURNER COVER ALL 615 / 624 / 636 / 648
21
G3-Z5905
1 CENTER WALL
615MF, 615TF
G3-Z5915 624MF, 624TF, 624TSPF, 624TCHSF
G3-Z5925 636MF, 636TF, 636TSPF, 636TCHSF
G3-Z5935 648MF, 648TF, 648TSPF, 648TCHSF
22 2F-Z5949 1/2/3/4 BURNER ALL 615 / 624 / 636 / 648
23
2K-Z5960
1 MANIFOLD
615MF
2K-Z5961 615TF
2K-Z5962 624MF, 624MFS
2K-Z5963 624TF, 624TSPF, 624TCHSF
2K-Z5964 636MF, 636MFS
2K-Z5965 636TF, 636TSPF, 636TCHSF
2K-Z5966 648MF, 648MFS
2K-Z5967 648TF, 648TSPF, 648TCHSF
24
2J-Z0792
1
PRESSURE REGULATOR NAT UNITS
H3-Z4557 REGULATOR-GAS 3/4 NPT LP LP UNITS
25 2V-Y8832 1/2/3/4 VALVE-MANUAL GAS 615MF / 624MF / 636MF / 648MF
26 2V-Z6647 1/2/3/4 PILOT BURNER
615MF / 624MF / 636MF / 648MF
615TF / 624TF / 636TF / 648TF
27 2V-6671 1/2/3/4 PILOT VALVE ALL 615 / 624 / 636 / 648
28 2P-1453
1
PIPE PLUG
615MF, 624MF, 636MF, 648MF
615TF, 624TF, 636TF, 648TF
3/4/5
624TSPF / 636TSPF / 648TSPF
624TCHSF / 636TCHSF / 648TCHSF
29
2A-Y1255 2/3/4 ORIFICE PROPANE 624 / 636 / 648 LP
2A-Z4930 1/2/3/4 ORIFICE #41, NAT 624 / 636 / 648 NAT
30 2K-Z5968 2/3/4 FITTING 1/4 MPT X 3/8 CC
624TSPF / 636TSPF / 648TSPF
624TCHSF / 636TCHSF / 648TCHSF
31 2K-Z4921
2/3/4
BURNER TUBE
624TSPF / 636TSPF / 648TSPF
624TCHSF / 636TCHSF / 648TCHSF
1/2/3/4 615TF / 624TF / 636TF / 648TF
32 2K-Z6081 2/3/4 PILOT TUBE
624TSPF / 636TSPF / 648TSPF
624TCHSF / 636TCHSF / 648TCHSF
PARTS LIST June 13, 2012, Rev -
