Star Max 648TF - Page 13

13
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 3
INCLUDE MODEL AND SERIAL NUMBER OF 3
Some items are included for illustrative purposes only and in certain instances may not be available.
Star International Holdings, Inc. Company
2M-Z16008 Star-Max Gas Griddles
Model: 615, 624, 636, 648 Star-Max Gas Griddles
Fig No Part No Qty Description Application
33 2J-Z0804 2/3/4 THERMOCOUPLE-PILOT
624TSPF / 636TSPF / 648TSPF
624TCHSF / 636TCHSF / 648TCHSF
34 G3-Z6124 2/3/4 PILOT BRACKET
624TSPF / 636TSPF / 648TSPF
624TCHSF / 636TCHSF / 648TCHSF
35 2A-9369
1/2/3/4
ORIFICE FITTING
615TF / 624TF / 636TF / 648TF
2/3/4
624TSPF / 636TSPF / 648TSPF
624TCHSF / 636TCHSF / 648TCHSF
36 2K-Y7111 1/2/3/4 ELBOW 1/4 MBT X 3/8 CC 615TF / 624TF / 636TF / 648TF
37
2T-Y7590
1/2/3/4
STEM-T-STAT
615TF / 624TF / 636TF / 648TF
2T-Z4293 THERMOSTAT
38 2J-Z5959 2/3/4 COMBINATION CONTROL
624TSPF / 636TSPF / 648TSPF
624TCHSF / 636TCHSF / 648TCHSF
PARTS LIST June 13, 2012, Rev -
