PARTS LIST December 13 2010, Rev. H
Some items are included for illustrative purposes only and in certain instances may not be available.
Star Manufacturing International, Inc.
1
2
Model: 11WLA, 11WLA-HS, 11WLA-P
Fig No. Part No Qty Description Application
1 N1-119030 1 CORD ASSY 120V 120V
1 N1-119033 1 CORD ASSY 120V(CSA) C/UL
1 N1-119034 1 CORD ASSY. 240V 240V
2 2P-Y6211 1 BRUSH 11WLA-HS, 11WLA-P
3 2C-Y5059 4 POP RIVET ALL
4 2I-Z0057 4 FOOT ALL
5 N1-Z0697 1 BOTTOM ALL
6 2K-Y2968 1 BUSHING STRAIN RELEIF ALL
7 2E-Y8233 1 TERMIINAL BOARD ALL
8 2R-Y8261 1 KNOB-THERMOSTAT ALL
9 2E-Z5884 1 SWITCH ALL
10 2M-Z0691 1 REAR PANEL (SIGN) ALL
13 N1-119039 1 BODY ASSY. (WARMER) 11WLA, 11WLA-P
13 N1-119040 1 BODY ASSY. (HEATED SPOUT) 11WLA-HS
14 O1-Y9787 1 BAND-ELEMENT ALL
16 2C-H5569 3 POP RIVET 1/8 x .6 ALL
17 2N-Z0205 1 ELEMENT 120V 120V, C/UL
17 2N-Z0665 1 ELEMENT 240V 240V
18 2C-1496 2 SCREW 8-32 x 3/4 STL. PH ALL
19 2C-H8670 1 WASHER-LOCK #8 ALL
20 2C-2556 3 NUT #8-32 ALL
21 2T-Z0245 1 THERMOSTAT ALL
22 N1-Z0700 1 BRACKET ALL
23 O1-Y9786 1 BAND-HEATER 11WLA-120V
24 N1-119038 1 HEAT-WELL 11WLA-120V
25 N1-Y3654 5 ANGLE-STIFFENER 11WLA-120V
26 2D-Y3464 BOWL-INSET ACCESSORY: SSB-11
27 2L-Y6596 COVER 11QT FORMED ACCESSORY: SSB-11
29 2R-Y9854 1 KNOB-BLK. 11WLA-HS-120V
30 2A-Y9637 1 NUT CYLINDER SLEEVE 11WLA-HS, 11WLA-P
31 N2-Y9848 1 PLATE-PLASTIC PUMP 11WLA-HS, 11WLA-P
32 2V-Y7661 1 PLUNGER-SHIELD 11WLA-P-120V
33 2A-Z0718 1 GUIDE PLUNGER 3” 11WLA-HS, 11WLA-P
34 2P-Z0830 1 SPRING 11WLA-HS-120V
35 N2-Y4146 1 WASHER, SPRIING COMPRESS TEFLN 11WLA-HS, 11WLA-P
