12
PARTS LIST June 30, 2008, Rev. L
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
Number
Per
Unit
Description
Star Manufacturing International, Inc.
MODEL
Part
Number
Key
Number
3WLA-3WSA 120V/240V
1 N2-30409 1 CORD ASSY. 120V
1 CORD ASSY. 240V
2 2C-2559 3 10-24 NUT
3 2C-Y5059 4 POP RIVET
4 2I-H7685 4 FOOT
5 N2-Y8542 1 BOTTOM
6 2K-7889 1 BUSHING 90°
7 2E-Y8233 1 TERMINAL BOARD
8 2R-Y8261 1 KNOB-THERMOSTAT
9 2E-Z5884 1 SWITCH
10 2M-Y8248 1 REAR PANEL (SIGN)
11 N2-Y8545 1 FRONT PANEL S.S.
12 2C-1631 1 SCREW #6 x 1/4
13 N2-30424 1 BODY ASSY. (HEATED SPOUT)
N2-30425 1 BODY ASSY. (WARMER)
14 N2-Y8130 1 BAND
15 N2-Y8310 1 PLATE
16 2C-H5569 3 POP RIVET 1/8 x .6
17 2N-Y8227 1 ELEMENT 120V
2N-Y8226 1 ELEMENT 240V
18 2C-Y8312 1 SCREW 8-32 x 1 FH
19 2C-H8670 2 WASHER-LOCK #8
20 2C-2556 2 NUT #8-32
21 2T-Y8262 1 THERMOSTAT
2T-Z0251 1 THERMOSTAT, PRESET (3WSA-HSS ONLY)
21a C3-Y8042 1 THERMOSTAT CLIP (3WSA-HSS ONLY)
22 N2-Y8129 1 BRACKET
23 N2-Y8127 1 BAND-HEATER
24 2A-Y8556 3 SPACER
25 N2-30423 1 BOWL ASSY.
26 N2-30455 1 BOWL SPACER
27 2D-H6295 1 STAINLESS INSET (OPTIONAL)
28 2R-Y5701 1 HANDLE
29 N2-30436 1 COVER
30 2L-Z0577 1 LADLE 1 OZ.
31 N2-30437 1 INSET
32 O2-Y5703 1 HINGE-LEAF
33 2B-Y5792 2 PIN-HINGE
34 2R-Y9854 1 KNOB-BLK.
35 2A-Y9637 1 NUT
36 2L-Y7618 1 COVER
N2-Z0253 1 COVER PUMP (3WSA-HSS ONLY)
37 2V-Y7661 1 PLUNGER-SHIELD
38 2A-Z0718 1 GUIDE
39 2P-Z0830 1 SPRING
40 N2-Y4146 1 WASHER
41 2I-Y9636 1 ROD/PLUNGER
42 2I-Y4143 1 O-RING
43 2P-Y6196 2 BALL-VALVE
44 2A-Y7658 1 NUT
45 2I-Z0730 1 PUMP CHAMBER
46 N2-Y9685 1 PIN-”U”
1
2
To Next Page
