WHEEL INSTALLATION LIGHT BULB REPLACEMENT
44 45
Read all of SAFETY and this section before attempting any procedure.
Pay particular attention to Notices, Cautions, Warnings and Dangers
WHEEL INSTALLATION
To decrease the risk of component damage, do not tighten
lug nuts to more than 85 ft. lbs. (115 Nm) torque.
Always follow the cross-sequence pattern when you install the lug nuts to make
sure the wheel is evenly seated against the Cross sequence hub.
• With the valve stem to the outside
of the wheel, install the wheel
on the hub with lug nuts.
• Tighten the lug nuts (1) with
yourngersinthecross-sequence
pattern shown.
• Tighten the lug nuts to 50 to
85 ft-lbs. (70 to 115 Nm) torque in
20 ft-lbs. (27 Nm) increments.
• Continue to follow the cross
sequence pattern until the
correct torque is reached.
Tire style may vary
1.
Valve Stem Cap
To Next Page
