2M-Z15996 Star-Max Electric 15lb Fryer
PARTS LIST December 16, 2015, Rev. B
Star Manufacturing International, Inc.
Model: 301HLF 15lbs Electric Fryer
Fig No. Part Number Quantity Description
1 2R-9572 1 KNOB-HARRY DAVIES#5754FI
2 E3-301060-PS 1 RELEASE ROD ASSEMBLY KIT
3 2A-Y1105 2 PIN-ROLL 3/32D X 1/2 STL
4 2P-9274 1 SPRING-RELEASE
5 E3-9269 2 BEARING-PIVOT
6 E3-9270 4 PLATE-ELEMENT SUPPORT
7 E3-7674 2 ANGLE-CAPILLARY RETAINER
8 2C-7139 4 SCREW #8X1/4 B THP STL NP
9 E3-Z20977 1 BACK-ELEMENT HOUSING
10 E3-EF0002 1 ELEMENT HOUSING ASSY
11 E3-Z15705 1 KNOB ASSEMBLY SM E-T KEYT
12 2M-Z15483 1 LABEL, KNOB ELEC. FRYER
13 2T-Z7268 1 THERMOSTAT, 200-375F
14 2J-Y6690 1 PILOT LIGHT 240V
15 2N-Z2920 1 ELEMENT-5500 WATT W/LEADS
16 2P-5737 6 CLIP- CAPILLARY TUBE
17 2C-1494 6 SCREW 8-32X1/2 RHP STL NP
18 E1-7363 4 CLAMP-THERMOSTAT BULB
19 2C-2556 18 NUT 8-32 HEX STL NP
20 2P-Y3453 4 WIRE SPACER - .350 DIA.
21 2B-9280 1 CLAMP, ELEMENT-REAR
22 2C-H1578 8 SCREW 8-32X1 PHS BR NP
23 E3-301043 1 HANDLE AND CLAMP ASSEM
24 2B-Y5940 2 LOWER ELEMENT CLAMP
25 2C-2555 8 NUT 8-32 ACHD BRS NP
26 2D-301007 1 KETTLE, FRYER-301 SERIES
27 2B-301042 1 BASKET ASSEMBLY RIGHT
28 2B-301041 1 BASKET ASSEMBLY LEFT
29 E3-Y7254 1 PANEL-BACK
30 2C-6349 42 SCREW #8X3/8 B THP STL NP
31 E3-Y7359 1 BRACKET, THERMOSTAT
32 2T-Z3209 1 THERMOSTAT-SAFETY
33
2K-8043 2 BUSHING HEYCO SB-875-10
34 2I-Z3378 1 GASKET-ELEMENT HOUSING
35 2E-Y5166 1 SWITCH-2 POLE 30 AMP
36 E1-Z15962 1 SWITCH GUARD SINGLE SST
37 2C-200067 2 SCREW 6-32X1/4 THP SS
38 2C-8477 3 CLIP .125 PO STL PHOS
39 2M-Z15804 1 LOGO, STAR-MAX
40 E3-EF0001 1 PANEL INSPECTION
41 E3-Y7265 1 PARTITION FRONT
42 E3-Y7331 1 PARTITION REAR
43 E3-Y7266 1 WIRE CHANNEL
44 E3-301063 1 BOTTOM ASSY 301HLD
45 2A-Z5942 4 FOOT, 1/2-13 X 4”L.
46 2K-Y6764 1 BUSHING - STRAIN RELIEF
NI E3-301044 1 CORD ASSY 12-3 SJTO 30A
