PARTS LIST October13,2010,Rev.D
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
1
2
Some items are included for illustrative purposes only and in certain instances may not be available.
MODEL
Star Manufacturing International, Inc.
GR14SPT-240V SPLIT LID TABLE TOP
CLAM SHELL TOASTER
Fig No Part No Qty Description Application
1 D9-GR0032 2 TORQUE BOX ASSEMBLY
2
D9-GR0150
1
GREASE CABINET ASSEMBLY
D9-GR0034 GREASE CABINET ASSY GR14SPTK
3 D9-GR0152 1 BODY ASSEMBLY
4 D9-GR0177 1 BURN GUARD ASSEMBLY - LEFT
5 D9-GR0176 1 BURN GUARD ASSEMBLY - RIGHT
6 D9-GR0156 1 REAR PLATE ASSEMBLY
7
D9-GR0518
1
GREASE DRAWER ASSEMBLY
D9-GR0517 GREASE DRAWER ASSY. -STD GR14SPTK
8 D9-GR0182 2 TOP RETAINING PLATE ASSEMBLY
9 PART OF ITEM #34
10 2A-Y6142 4 SLEEVE HANDLE
11 2A-Z11501 4 FOOT 1” SOLID RUBBER
12
2B-Z3336
4
14” GR14SPT ARM
2B-Z10355 ARM, CG/GR14SPT W/45° FRONT GR14SPTK
13 2C-Z3200 4 PIN - TOP HOUSING
14 2C-Z3350 2 HALF CLAMP - .188 DIA.
15 2E-Z3808 1 SWITCH TOGGLE
16 2E-05-07-0350 1 TRANSFORMER 230V/10V 6VA
17 D9-GR0194 1 CORD POWER
18 2E-Z2894 1 TERMINAL BLOCK (304)
19 D9-Z3903 2 BRACKET, PROBE MOUNT
20 2E-Z3278 2 RTD PROBE - 48” LONG WIRE
21 2E-Z3335 2 RELAY DBL POLE-SNGL THR
21 2E-Z3335 1 RELAY DBL POLE-SNGL THR GR14SPTK
22 PS-GR0361 1 KIT, 2F-Z1945 CASTING, SM. BOT., ALUM.
23 PS-GR0356 2 KIT, 2F-Z3237 CASTING - TOP
24 2I-05-07-0013 1 BOOT SWITCH
25
2J-Z3263
1
TIME/TEMP CONTROL-HARDWARE
D9-GR0380 TIME/TEMP CONTROL F/C GR14SPTK
26 2K-Y6764 1 BUSHING 90 SR 17-2
27 2K-Z1971 14 SPACER
28 2M-12-07-0038 1 LABEL ON & OFF
30 2M-Z2620
2 LABEL CAUTION, BI-LINGUAL
31 2M-Z2764 1 LABEL-PATENT PENDING
32
2M-Z3337
1
OVERLAY
2M-Z10087 OVERLAY GR14SPTK
33 2N-Z9327 1 ELEMENT, HEATING, 1300 W
34 PS-Z9326 2 ELEMENT, HEATING, TOP 500W
35 2R-Z3345 1 COUNTER BALANCE - SPLIT TOP
36 2V-Z3152 2 HANDLE - TACO BELL 2
37 2V-Z3252 2 TOP HOUSING LATCH ROD
