- 6 -
Working Size(L×W×H)： TRANSPORTATION
69×50×105cm 1.Always shut off engine when transporting machine．
2.Make sure lifting device has enough capacity to
hold machine(see identification plate on machine
for weight)．
3.Use central lifting point(a)when lifting machine．
4.Trolley wheel(b)is used for short distance
transportation．
TROUBLE SHOOTING
SYMPTOM
POSSIBLE CAUSES
SOLUTION
Travel speed too low，
and vibration is weak.
Engine speed too low?
Set engine speed to correct RPM．
Clutch slips?
Check or replace clutch．
V-belt slips?
Adjust or replace V-belt．
Excessive oil in vibration?
Drain excess oil and fill to proper level．
Malfunction in vibrator
housing?
Check eccentric, gears and counter weights.
Bearing Failure?
Replace Bearing
Insufficient engine output?
Check engine, compression etc．
