Stark 61041 User Manual

Code Name Type Qty Note
1
Flat gasket
6*18*2 4pcs
2
Hexagon screw
M6*12 4pcs
3
Countersunk
head hexagon
screw
5/16-24-16 2pcs
4 Double end bolt M8*40 4pcs
Flange nut M8 4pcs
5
Flat key
4.78*50 1pc
6 Clutch adjusting
pad
Ø20 4pcs
7 Shaft head bolt 5/16-24-25 1pc
Spring gasket
Ø
8 1pc
Tapered flat
gasket
8*30 1pc
8 Outer hexagon
bolt
M8*35 1pc
Locknut M8 1pc
Flat gasket Ø8 2pcs
9
Belt cover
bracket
1pc
10
Clutch assembly
Ø19.05 1pc
11 Ribbon 4pcs
12
V belt
A-584 1pc
13 lower handle 1pc
Including lifting screw,upper handle
retaining bolt M8*120(1 pc) and
bakelite bolt etc.
14 Upper handle 1set
15
Belt cover
1set
16
Main body
1set
17 Engine 1pc
Including throttle lever assembly
4
