Installation
WARNING
Installer must be suitably qualified and ensure compliance with all local codes and
standards including AS/NZS 3500.1.
Failure to comply even partially with installation instructions may void the
warranty.
Positioning
Unpack machine, check for damage and complete delivery. Install machine on
sound waterproof self-draining floor and use adjustable feet to level machine.
Adjacent surfaces should be heat resistant and moisture proof, especially benchtop
lower surfaces above undercounter machines. Allow room for detergent to one
side of machine or in adjacent cupboard. 20litre container requires about 450H x
250W x 350D, but smaller containers are available from many suppliers.
Hot Water Supply
Temperature 65°C ± 5°C
Pressure 200-350KPa = 30-50 Psi.
Connection 20 mm (3/4” BSP) male
Flow rate minimum 20 litres per minute
Water consumption 2 litres per cycle approximately
Backflow prevention Atmospheric Vacuum Breaker fitted standard
Pressure limiter may be required. . Don’t use small diameter plastic supply lines.
FLUSH supply line before connection. Poor quality supply or excessive water
hardness may affect performance or damage machine – filtration and/or softening
is recommended.
Waste
Drain pump is fitted standard – see installation diagram.
Power
Electrical supply required is 13A 230V 50Hz via switched outlet adjacent to
machine, which is supplied with cord set including 15A plug.
Detergent
Insert detergent pump inlet hose into container of commercial low foam detergent.
The detergent hoses will be primed during filling of the wash tank.
Detergent pump is set to run continuously during filling of the machine. It is also
set to operate for 12 seconds at the beginning of the wash cycle. This time can be
adjusted in User Settings of the keypad controller. Press both Up and Down keys
on the keypad for a few seconds to access the User Setting menu and follow
onscreen instructions.
Commercial detergents can be hazardous – read instructions and handle with care.
Installation Checklist
Complete attached Installation Checklist to ensure machine is installed and
running correctly, and operator is familiar with operating procedures.
