3. Place rubber sealing washers over
holes followed by mount. Liberally apply
silicone sealant to ll holes on mount.
4. Apply silicone sealant to threads and insert
the lag bolts with a washer. Use the drill with
7/16” socket to drive screws ~90% in.
5. Use the socket wrench to tighten screws to
snug plus 1/4 turn; do not overtighten.
1. Using the Wedge Mount as a guide, mark the four corner
hole locations with the pencil and remove mount.
2. Drill four 3/32” (2 mm) holes through the surface
at the marked locations. Remove burrs around
holes and make sure the surface is free of debris.
Option 2 – Lag Bolts
INSTALLATION
