S8010
119
ENGLISH
The HIGH (HI) speed is recommended for drilling wood and wood composites.
The use of this speed range is indicated for use abrasives and polishing
coupled with accessories.
WARNING: AVOID working with Drill / Driver in the LO speed for long
periods of time.Working under this condition constantly may cause the
machine to overheat.
1 3 5
1 3 5
TWO SPEED GEARBOX SWITCH
(slide switch)
position: HIGH SPEED (HI)
position: LOW SPEED (LO)
17 19 21 23
FIG.11
KEYLESS
CHUCK
GRIP
RELEASE
FIG 07
ADJUSTABLE TORQUE CHUCK:
FIG 08
