ENGLISH
PROCEDURE TO REMOVE A DRILL, HOLE SAW AND BIT:
1. LOCK the Trigger Switch of the Drill / Driver, putting the button of the
Direction of Rotation Selector (NORMAL / LOCK / REVERSE) the center posi-
tion (LOCK);
2. OPEN the Chuck by hand with a light torque;
3. REMOVE the drill bit ou the support of hole saw or the bit;
WARNING: TURN the chuck body towards TIGHTENING (close the chuck).
DO NOT USE any kind of key to tighten or release the Chuck.
DRILLING PROCEDURE:
1. CHECK if the Direction of Rotation Selector is positioned as the desired
setting (NORMAL) (fi gure 04);
DRILL BIT
PLACED THE
WRONG WAY
FIG 11B
