StarTech.com USB32HD2 User Manual

1
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.StarTech.com/support
Table of Contents
Requirements .........................................................................................2
Package Contents...................................................................................2
Product Diagram ....................................................................................3
Installation ..............................................................................................4
Hardware Installation ..............................................................................................................................5
Software Installation ................................................................................................................................ 6
Operation ................................................................................................11
Display Conguration ..............................................................................................................................11
Audio Conguration ................................................................................................................................29
Troubleshooting ..................................................................................... 31
Compliance Statements ........................................................................39
Safety Statements ..................................................................................40

StarTech.com USB32HD2 Specifications

General

Chipset	Trigger T6-688SL, Silicon Image - Sil9136-3
DVI output	No
HDMI output	Yes
USB version	3.2 Gen 1 (3.1 Gen 1)
Internal memory	64 MB
USB connector type	USB Type-A
USB connector gender	Male
Audio output channels	2.0 channels
Maximum resolution (HDMI)	3840 x 2160 pixels
Number of displays supported	2
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800, 1366 x 768, 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2048 x 1152, 3840 x 2160
Sustainability certificates	CE, RoHS
Minimum RAM	4096 GB
Minimum processor speed	2.4 GHz
Minimum processor family	Core i5
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Storage temperature (T-T)	-20 - 75 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Product color	Black
Housing material	Plastic
USB cable length	0.25 m
Master (outer) case width	310 mm
Master (outer) case height	430 mm
Master (outer) case length	445 mm
Harmonized System (HS) code	84733020
Quantity per master (outer) case	40 pc(s)

Weight and Dimensions

Depth	315 mm
Width	66 mm
Height	15 mm
Weight	56 g
Package depth	207 mm
Package width	144 mm
Package height	38 mm
Package weight	184 g
