STARTRITE 403 - Page 23

23
11. Parts Lists and Diagrams - 403/UK1 and 403/UK3
142 Lock handle JL26040015-001S 1
143 Bracket JL26040008 1
144 Set screw M6X12GB77Z12D9 4
145 Gear 1501006 1
146 Plate JL26040007 1
147 Screw JL26040006 1
148 Cover BS5001050001 1
149 Screw M8X16GB70D1Z 4
150 Cover BS5001050002 1
151 Pan head screw M4X4GB823B 2
152 Rack JL26040001 1
153 Screw M4X10GB819D1Z 3
154A Bracket BS5001052001 1
155 Screw M8X20GB70D1Z 1
156A Guide post JL26041004 1
156B Screw M8X16GB70D1Z 1
156C Tube JL26041006 1
156D Screw M8X30GB70D1Z 1
156E Screw M8X40GB70D1Z 2
156F Tube JL26041002 2
156G Bearing BRG6201-2RSGB276 5
156H Flat washer WSH8GB97D1Z 3
156I Guide shaft JL26041003 3
156J Upper guide JL26041001 1
157 Composite bolt JL20061003A-001S 1
158 Small countersunk head riveted nut M6X15GB/T17880D3Z 1
161A Blade guard BS4001051000C-105U 1
162A Guide post BS4001050001B 1
164 Screw M5X10GB70D1Z 2
165 Large washer WSH5GB96D1Z 2
167 Large washer WSH6GB96D1Z 1
169 Screw M6X16GB70D1Z 2
170 Pan head screw M5X10GB818B 3
171 Handle 1501009-20001S 1
172 Large hand wheel JL26030012-001S 1
173 Retaining ring CLP12GB884B 1
174 Set screw M5X8GB78Z12D9 1
175 Tube JL26040003 1
176 Worm JL26040004 1
177 Hex bolt M8X20GB5783Z 4
178 Large washer WSH8GB96D1Z 4
179 Protective cover BS5001052002A 1
180 Flat washer WSH5GB97D1Z 4
181 Screw M5X10GB818Z 4
No. Description Part Number Quantity No. Description Part Number Quantity
Upper Guide Assembly
