Front Panel Display

System OK – Green OFF

System Trouble – Yellow ON

Indicates

Status

Detection Field Wiring Problem

Possible Open Condition

• Check to see if SDRP to field wiring circular

connector is tight and connected

• Check to see if end of line device is in place

• Check all sensors and wiring

• Check for any wiring damage or breaks

Actuation Field Wiring Problem

Possible Open Condition

• Check to see if SDRP to field wiring circular

connector is tight and connected

• Check Stat-X generator to field wiring connection

is intact

• Check for corrosion at Stat-X generator to field

wiring connection

• Check actuation circuit for any breaks or damage

• Verify Stat-X generator has not discharged

Manual Release Switch Problem

Possible Open Condition

• Check to see if SDRP to field wiring circular

connector is tight and connected

• Check field wiring to Manual Release Switch

circular connector is tight and connected

• Check field wiring to manual release switch for any

breaks or damage

Disable Switch Position

• Check the “Arm System-Disable System” toggle

switch is in the proper position

Internal Battery Problem

Possible Low Voltage Condition

• Check replacement date for batteries, if more than

three (3) years, replace batteries
