WINCH MANUAL
SPECIFICATIONS

SPECIFICATIONS
Rated line pulls 13500 lbs (6123 kgs)
Gear reduction ratio 265:1
Motor 12V:Input: 4.6kW / 6.1hp; Output: 2.1kW / 2.8hp
24V:Input: 6.5kW / 8.7hp; Output: 2.8kW / 3.8hp
Overall dimensions 542 mm ×160mm ×245mm (21.3”×6.3”×9.65”)
Drum size Ø63mm×223 mm (Ø2.48 “×8.8 “)
Cable
Synthetic rope Wire rope
Ø10mm×20m (Ø0.39”×65.6 ‘)
Ø9mm×30m (Ø0.35”×98.4 ‘)
Ø10.2mm×20m (Ø0.4”×65.6 ‘)
Net Weight
Synthetic rope Wire rope
28kg (61.7 lbs) 35kg (77.2 lbs)
Pull, Speed, Amperes, Volts (First layer):
Line Pull Line Speed ft/min (m/min) Current A
Ibs (kgs) 12V DC 24V DC 12V DC 24V DC
0 19.7 (6.0) 20.6 (6.3) 72 50
4000(1814) 10.5 (3.2) 11.5(3.5) 180 120
8000(3629) 7.5 (2.3) 8.9 (2.7) 265 180
12000(5443) 5.2 (1.6) 6.9 (2.1) 360 240
13500(6123) 3.9 (1.2) 5.2(1.6) 390 270
Line Pull And Rope Capacity In Layer
Layer Rated line pull lbs (kgs) Total rope on the drum ft (m)
1 13500(6123) 16.1(4.9)
2 10596(4806) 36.4(11.1)
3 8720(3955) 60.0(18.3)
4 7408(3360) 65.6(20.0)
13V2S12, 13V2A12, 13V2S24, 13VAE12
