WINCH MANUAL
SPECIFICATIONS
# sku Qty Description
1 1350001 3 Terminal Protect
2 13500100 1 Motor Assembly
3 1350002 6 Cap Screw M10 x 35
4 1350003 6 Lock Washer Φ10
5 1350004 6 Think Flat Washer Φ10
6 1350005 4 Hex Nut M10
7 13500200 1 Break / Shaft Assembly
8 1350006 2 Bushing—Drum
9 1350007 1 Six Angle Bar
10 1350008 2 Ring Seals
11 1350009 1 Screw M8 x 10
12 1350010 4 Lock Washer Φ8
13 1350011 4 Cap Screw M8 x 30
14 1350012 2 Tie Bar
15 13500300 1 Drum Assembly
16 1350013 8 Screw M5 x 18
17 1350014 8 Lock Washer Φ5
18 1350015 1 End Bearing
19 1350016 1 Gasket
20 1350017 1 Gear-Ring
21 13500400
1 Gear Carrier
Assembly(Output)
22 13500500
1 GearCarrier Assembly
(intermediate)
23 13500600
1 Gear Carrier Assembly
(Input)
24 1350018 1 Gear—Input Sun
25 1350019 1 Trust Washer
26 1350020 1 Gear—Housing
27 1350021 1 Clutch Screw
28 1350022 1 Ring Seals
29 1350023 1 Clutch Handle
30 1350024 2 Locknut M10
31 1350025
1 Aluminium Fairlead (For
synthenic rope)
32 13500700
1 Roller Fairlead
(For steel rope)
# sku Qty Description
33 1350026
1 Mounting Channel
(Optional)
34 13500800 1 Switch(RC3)
35 13500900 1 Remote Controller
36 135001000 1 Cable Assembly
37 1350027 1 Strap
38 135001100 1 Control Section
WINCH PARTS LIST 13V2S12, 13V2A12, 13V2S24, 13VAE12
